The Fluke MDA-550-III oscilloscope, with its rugged design and ease of portability, is suitable for use in industrial environments and repair workshops. This device features four isolated input channels, enabling simultaneous measurement of various signals.
A bandwidth of 500 MHz and high sampling rate provide high accuracy in analyzing complex signals. Specific features such as harmonics measurement, motor shaft voltage measurement, and voltage and current imbalance make this device a comprehensive tool for motor drive system analysis.
🔹 Key Features of Fluke MDA-550-III
-
Four isolated input channels
-
500 MHz bandwidth
-
High sampling rate
-
Harmonics and motor shaft voltage measurement
-
Capability to measure input and output voltage and current
-
Rugged and portable design
-
Graphical guide for measurements
🔹 Technical Specifications of Fluke MDA-550-III
| Feature | Value |
|---|---|
| Number of Channels | 4 |
| Bandwidth | 500 MHz |
| Sampling Rate | High |
| DC Voltage Measurement Accuracy | ±(1.5% + 6 counts) |
| AC Voltage Measurement Accuracy | ±(1.5% + 10 counts) |
| Current Measurement Accuracy | ±(2% + 5 counts) |
| Harmonic Measurement Accuracy | ±(3% + 5 counts) |
| Motor Shaft Voltage Measurement Accuracy | ±(2% + 4 counts) |
| Permissible Input Voltage | 1000 V (CAT III) / 600 V (CAT IV) |
| Operating Temperature | 0 to 40 degrees Celsius |
| Operating Humidity | 0 to 95% (non-condensing) |
❓ Frequently Asked Questions (FAQ)
Q: Is this device suitable for use in high-voltage industrial environments?
A: Yes, this device is designed according to CAT III 1000V and CAT IV 600V standards, making it suitable for high-voltage industrial environments.
Q: Does the MDA-550-III have the capability to measure harmonics?
A: Yes, this device has the capability to measure harmonics up to the 51st harmonic, allowing for precise power quality analysis.
Q: Is this oscilloscope easily portable?
A: Yes, the rugged and portable design of this device makes it suitable for use in industrial environments and repair workshops.
🔚 Conclusion
The Fluke MDA-550-III, with advanced features such as a 500 MHz bandwidth, four isolated input channels, and the capability to measure harmonics and motor shaft voltage, is an ideal tool for maintenance and repair engineers in various industries. This device, with high safety standards and rugged design, ensures accurate and safe performance in industrial environments.
📎 Official Datasheet Link
👉 Download the datasheet for Fluke MDA-550-III (PDF)
