The model Fluke 190-502-III-S from the Fluke 190 series features a bandwidth of 500 MHz, two isolated channels, and a sampling rate of 5 GSamples per second, capable of precise analysis of high-frequency signals. This device has isolated inputs with a maximum voltage of 1000 volts in CAT III and 600 volts in CAT IV.
This Scopemeter is built with a rugged design and an IP51 protection rating, making it suitable for use in industrial environments. It also has long-term recording modes such as ScopeRecord and TrendPlot for capturing and analyzing transient and long-term data.
🔹 Key Features of Fluke 190-502-III-S
-
Bandwidth of 500 MHz
-
Two isolated channels with independent inputs
-
Sampling rate of 5 GSamples per second
-
Isolated inputs with a maximum voltage of 1000 volts in CAT III and 600 volts in CAT IV
-
Long-term recording modes ScopeRecord and TrendPlot
-
Rugged design with IP51 protection rating
-
Rechargeable battery with a runtime of up to 7 hours
-
USB interfaces for data transfer to a computer
🔹 Technical Specifications (Fluke 190-502-III-S)
| Feature | Value |
|---|---|
| Number of Channels | 2 Isolated Channels |
| Bandwidth | 500 MHz |
| Rise Time | 0.7 ns |
| Sampling Rate | 5 GSamples per second |
| Isolated Inputs | Maximum 1000 volts CAT III / 600 volts CAT IV |
| Recording Modes | ScopeRecord, TrendPlot |
| Protection Rating | IP51 |
| Battery Runtime | Up to 7 hours |
| Communication Interfaces | USB |
| Dimensions | 265 × 192 × 70 mm |
| Weight | Approximately 2.2 kg |
❓ Frequently Asked Questions (FAQ)
Question 1: Is this device suitable for use in industrial environments?
Answer: Yes, this Scopemeter has an IP51 protection rating and high voltage isolated inputs, making it suitable for industrial environments.
Question 2: Is data transfer to a computer possible?
Answer: Yes, data can be transferred to a computer for analysis using the USB interfaces.
Question 3: How long does the battery of this device last?
Answer: The rechargeable battery of this device provides up to 7 hours of continuous operation.
🔚 Conclusion
The Fluke 190-502-III-S Scopemeter, with features like a bandwidth of 500 MHz, two isolated channels, and a sampling rate of 5 GSamples per second, is an ideal tool for analyzing complex signals in industrial environments.
Its rugged design and protection rating make it suitable for use in harsh industrial conditions.
