The Fluke IR189USB interface is an essential tool for engineers and technicians transferring recorded data from Fluke equipment to a computer for analysis and documentation.
This interface connects to the device via an infrared sensor and transfers data to the computer through a USB port. Thanks to its optical isolation data transfer technology, there is no risk of reverse voltage or electrical noise between the measuring device and the computer.
Fluke IR189USB is designed for use with a wide range of Fluke equipment, including:
-
180 and 280 series multimeters
-
725 and 726 series calibrators
-
Industrial testers and Process Tools
-
Some models of Clamp Meters with an optical port
This cable allows for data transfer, viewing, charting, and data storage through the proprietary FlukeView Forms software.
🔹 Key Features of Fluke IR189USB
-
USB optical interface for measurement data transfer
-
Compatible with FlukeView Forms software
-
Complete isolation to eliminate electrical interference
-
Easy installation with automatic drivers (Plug & Play)
-
Supports Windows 10 and 11
-
Durable cable with tear-resistant protective coating
🔹 Technical Specifications of Fluke IR189USB
| Feature | Value |
|---|---|
| Connection Type | Infrared Optical to USB |
| Cable Length | 1.2 meters |
| Electrical Isolation | Complete (Optical Isolation) |
| Data Transfer Rate | 9600 bps |
| Software Compatibility | FlukeView Forms, Fluke Calibration Tools |
| Supported Operating Systems | Windows 10 / 11 (64-bit) |
| Power Supply | Via USB port |
| Weight | 0.2 kilograms |
❓ Frequently Asked Questions (FAQ)
Is IR189USB compatible with all Fluke devices?
No, it is designed only for models that have an optical port (IR Port).
Does it need driver installation?
No, drivers are automatically recognized upon installing FlukeView Forms software.
Is data transfer done wirelessly?
No, the connection is made through optical wired but isolated from electrical supply.
Is the cable shock-resistant?
Yes, the cable features a durable PVC coating and industrial connectors.
🔚 Conclusion
The Fluke IR189USB interface cable is a vital tool for documenting, recording, and analyzing test and measurement data. With a safe, isolated design and complete compatibility with FlukeView Forms software, it ensures high-accuracy data transfer without risk.
📎 Official Datasheet Link
👉 Download the Fluke IR189USB datasheet (PDF)
