The Fluke 1674FC UK is part of the 1670 series, designed for professional applications and large projects, with enhanced features compared to the basic models. This device allows you to perform various installation tests quickly, accurately, and safely.
This model offers features such as:
-
Automatic Test (Auto Test) for executing pre-defined test sequences
-
The Insulation PreTest feature that stops the insulation test if the device detects that equipment is connected to the circuit to prevent damage to the equipment
-
Wireless connectivity and data transfer to mobile or computer with Fluke Connect
-
Support for earth resistance testing without circuit interruption using a clamp meter
-
Color touch interface, simple and user-friendly menus
-
Support for SPD (Surge Protection Device) and IMD (Insulation Monitoring Device) testing
🔹 Key Features of Fluke 1674FC UK
-
Insulation test voltages: 50 / 100 / 250 / 500 / 1000 volts
-
High-accuracy earth resistance testing with leakage current measurement capability
-
Color touch display and visual menu
-
Auto Test capability for automatic execution of tests
-
Insulation PreTest to prevent equipment damage
-
SPD and IMD testing
-
Safety: CAT III 600V / CAT IV 300V rating
-
Storage of results and reporting
-
Robust design suitable for field work
🔹 Technical Specifications of Fluke 1674FC UK
| Feature | Value / Range |
|---|---|
| Insulation test voltage | 50 / 100 / 250 / 500 / 1000 volts |
| Device Size | 26.25 × 14.19 × 11.93 cm |
| Weight with battery | Approximately 1.6 kg (3.5 lbs) |
| Battery | Li-ion battery model BP290, 10.8 volts, 2500 mAh |
| Environmental Protection (Ingress) | IP40 |
| Device Safety | Meets CAT III 600V / CAT IV 300V standards |
| Internal Memory | Stores test results and allows data transfer |
| Other Features | Support for SPD, IMD, earth testing, leakage current testing, Auto Test |
❓ Frequently Asked Questions (FAQ)
Does the Fluke 1674FC differ significantly from the 1673FC?
Yes, the 1674FC, in addition to the features of the 1673FC model, includes earth resistance testing capability, the Insulation PreTest feature, and supports SPD/IMD.
Is wireless data transfer possible?
Yes, the FC model can wirelessly transfer data to mobile devices or computers via Fluke Connect.
Is there a risk of damaging equipment?
The Insulation PreTest feature in this device checks whether equipment is connected to the circuit before performing the insulation test; if so, it stops the test to avoid potential damage.
