Fluke Model 115 is a professional digital multimeter from the popular Fluke brand, designed for general and advanced testing in facilities, factories, and technical environments. This device offers high accuracy measurements of AC/DC voltage, current, resistance, frequency, capacitance, diode testing, and continuity testing.
The Fluke 115 features AutoVolt for automatic detection of AC or DC voltage and LoZ for eliminating ghost voltages. These features make the Fluke 115 a reliable and quick choice in industrial conditions where accuracy and speed are crucial.
The large backlit display, Data Hold function, and safety class CAT III 600V make this tool an impeccable option for everyday and specialized tasks.
🔹 Key Features of Fluke Model 115
-
AC/DC Voltage Measurement up to 600 Volts
-
Current Measurement up to 10 Amperes
-
Diode Testing and Continuity Testing with Buzzer
-
Frequency and Capacitance Measurement
-
AutoVolt and LoZ functions for true voltage detection
-
Data Hold Function
-
6000 Count Digital Display with Backlight
-
Compact and Rugged Design for Field Use
-
Safety Standard: CAT III 600V
🔹 Technical Specifications of Fluke Model 115
| Feature | Value |
|---|---|
| DC Voltage | Up to 600V |
| AC Voltage | Up to 600V |
| Current | Up to 10A |
| Resistance | Up to 40 MΩ |
| Capacitance | Up to 10,000 µF |
| Frequency | Up to 50 kHz |
| Diode & Continuity Testing | Yes |
| AutoVolt / LoZ | Yes |
| Display | 6000 Count, Backlight |
| Battery | 9 Volt |
| Dimensions | 167×84×46 mm |
| Weight | 550 grams |
| Safety | CAT III 600V |
